Littelfuse 2.5A Resettable Surface Mount Fuse, 30V dc [30R250UU]; 174-0826
by Littelfuse
0₫
Mã kho: 1740826
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Trip Current | 5A |
| Voltage Rating | 30 V dc |
| Time to Trip | 10.3s |
| Hold Current | 2.5 A |
| Maximum Current | 40 A |
| Length | 11.4mm |
| Height | 18.3mm |
| Width | 3mm |
| Terminal Material | Tin Plated Copper Clad Steel |
| Minimum Resistance | 0.02Ω |
| Maximum Resistance | 70mΩ |
| Power Dissipation | 1.2W |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Dimensions | 11.4 x 3 x 18.3mm |
| Fuse Speed | F |
| Body Material | Polymer |
| Operating Temperature Range | -40 → +85 °C |
| Series | 30R |
