Littelfuse 375mA FF Surface Mount Fuse, 125V ac/dc [0451.375MRL]; 541-3344
by Littelfuse
0₫
Mã kho: 5413344
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Current Rating | 375 mA |
| Voltage Rating | 125 V ac/dc |
| Length | 6.1mm |
| Width | 2.69mm |
| Height | 2.69mm |
| Dimensions | 6.1 x 2.69 x 2.69mm |
| Fuse Speed | FF |
| Body Material | Ceramic |
| Breaking Capacity at Maximum Voltage Rating | 50 A @ 125 V ac/dc |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +125°C |
| Terminal Material | Gold Plated |
| Operating Temperature Range | -55 → +125 °C |
