Cooper Bussmann 2.5A Radial F Non-Resettable Wire Ended Fuse, 250V ac [SS-5F-2-5A-BK]; 169-9542
0₫
Mã kho: 1699542
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Current Rating | 2.5 A |
| Lead Orientation | Radial |
| Voltage Rating | 250 V ac |
| Fuse Speed | F |
| Body Material | Plastic |
| Body Length | 8.5mm |
| Body Width | 4.3mm |
| Body Height | 8.35mm |
| Wire Length | 4.8mm |
| Wire Pitch | 5.08mm |
| Breaking Capacity at Maximum Voltage Rating | 50 A @ 250 V ac |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Wire Diameter | 0.6mm |
