Singlfuse 2410 fast-acting 20A [SF-2410F2000T-2]; 191-4593
by Bourns
0₫
Mã kho: 1914593
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Current Rating | 20 A |
| Voltage Rating | 125 V ac |
| Length | 6.1mm |
| Width | 2.6mm |
| Height | 2.6mm |
| Dimensions | 6.1 x 2.6 x 2.6mm |
| Fuse Speed | F |
| Body Material | Ceramic |
| Breaking Capacity at Maximum Voltage Rating | 50 A @ 65 VAC, 50 A @ 65 VDC, 300 A @ 24 VDC |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +125°C |
| Series | SF-2410F-T |
| Resistance | 2.5mΩ |
| Operating Temperature Range | -55 → +125 °C |
