Bourns 3.5A Surface Mount Resettable Fuse, 30V [MF-S350]; 817-1719
by Bourns
0₫
Mã kho: 8171719
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Trip Current | 6.3A |
| Voltage Rating | 30 V |
| Time to Trip | 3s |
| Hold Current | 3.5 A |
| Maximum Current | 100 A |
| Length | 14mm |
| Height | 1.1mm |
| Width | 13.5mm |
| Terminal Material | Quarter Hard Nickel |
| Minimum Resistance | 0.017Ω |
| Maximum Resistance | 31mΩ |
| Power Dissipation | 2.5W |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Operating Temperature Range | -40 → +85 °C |
| Dimensions | 14 x 13.5 x 1.1mm |
