RS PRO AFG21125 Function Generator & Counter 25MHz USB; 123-3533
by RS PRO
0₫
Mã kho: 1233533
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Frequency Range Sinewave | 25MHz |
| Minimum Frequency Range Sinewave | 0.1Hz |
| Maximum Frequency Range Square Pulse and Arbitrary Waveform | 25MHz |
| Minimum Frequency Range Square Pulse and Arbitrary Waveform | 0.1 Hz |
| Maximum Frequency Range Triangle/Saw | 1MHz |
| Minimum Frequency Range Triangle/Saw | 0.1Hz |
| Digital Frequency | Yes |
| Digital Amplitude and Offset | Yes |
| Internal Linear and Log Sweep | Yes |
| Variable Sweep | Yes |
| Internal and External Amplitude Modulation | Yes |
| FM Modulation | Yes |
| Time Base Accuracy | ±20ppm |
| Height | 107mm |
| Minimum Operating Temperature | 0°C |
| Frequency Range Square Pulse and Arbitrary Waveform | 0.1 Hz → 25 MHz |
| Interface Type | USB |
| Dimensions | 266 x 293 x 107mm |
| Output Impedance | >300 (Output Disabled) kΩ, 50 (Fixed) Ω |
| Length | 266mm |
| Width | 293mm |
| Maximum Operating Temperature | +40°C |
| Output Amplitude | 1 mV Pk-Pk → 5 V Pk-Pk, 2 mV Pk-Pk → 10 V Pk-Pk (Open Circuit) |
| Plug Type | UK |
| Weight | 2.5kg |
| Model Number p | AFG21125 |
| Input Impedance | 1 kΩ |
