Toshiba TC74HC74AF(F) Dual D Type Flip Flop IC, 2 → 6 V, 14-Pin SOP [TC74HC74AF(F)]; 541-9500
by Toshiba
0₫
Mã kho: 5419500
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Logic Family | HC |
Logic Function | D Type |
Input Type | Single Ended |
Output Signal Type | Differential |
Triggering Type | Positive Edge |
Polarity | Inverting, Non-Inverting |
Mounting Type | Surface Mount |
Package Type | SOP |
Pin Count | 14 |
Set/Reset | Yes |
Number of Elements per Chip | 2 |
Maximum Propagation Delay Time @ Maximum CL | 150 ns @ 2 V |
Dimensions | 10.3 x 5.3 x 1.5mm |
Maximum Operating Temperature | +85 °C |
Minimum Operating Temperature | -40 °C |
Propagation Delay Test Condition | 50pF |
Maximum Operating Supply Voltage | 6 V |
Width | 5.3mm |
Minimum Operating Supply Voltage | 2 V |
Height | 1.5mm |
Length | 10.3mm |
