Texas Instruments SN74ABT823DBR 9-bit D Type Flip Flop IC, 3-State, 24-Pin SSOP [SN74ABT823DBR]; 162-6386
0₫
Mã kho: 1626386
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Logic Family | 74ABT |
| Logic Function | D Type |
| Input Type | Single Ended |
| Output Type | 3 State |
| Output Signal Type | Single Ended |
| Triggering Type | Positive Edge |
| Polarity | Non-Inverting |
| Mounting Type | Surface Mount |
| Package Type | SSOP |
| Pin Count | 24 |
| Set/Reset | Master Reset |
| Number of Elements per Chip | 9 |
| Maximum Propagation Delay Time @ Maximum CL | 6.8ns |
| Dimensions | 8.5 x 5.6 x 1.95mm |
| Minimum Operating Temperature | -40 °C |
| Length | 8.5mm |
| Width | 5.6mm |
| Minimum Operating Supply Voltage | 4.5 V |
| Maximum Operating Supply Voltage | 5.5 V |
| Maximum Operating Temperature | +85 °C |
| Propagation Delay Test Condition | 50pF |
| Height | 1.95mm |
