Intel WG82574IT S LBAC, Ethernet Controller, 10 Mbps, 100 Mbps, 1000 Mbps, PCI, 1.05 V, 1.9 V, 3.3 V, 64-Pin PQFP [WG82574IT S LBAC]; 682-7438
by Intel
0₫
Mã kho: 6827438
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Physical Network Type | 10BaseT, 100BaseTX, 1000BaseT |
Host Interface | PCI |
Network Interface | GMII, MII, RMII |
Communication Mode | Full Duplex, Half Duplex |
Data Rate | 10 Mbps, 100 Mbps, 1000 Mbps |
Loopback Mode | Internal |
Standard Supported | IEEE 802.3ab |
Mounting Type | Surface Mount |
Package Type | PQFP |
Pin Count | 64 |
Auto-Negotiation | Yes |
DMA Support | Yes |
Typical Operating Supply Voltage | 1.05 V, 1.9 V, 3.3 V |
Dimensions | 9 x 9 x 2.55mm |
Length | 9mm |
Maximum Operating Temperature | +85 °C |
Height | 2.55mm |
Width | 9mm |
Minimum Operating Temperature | -40 °C |
