RS PRO 5 Core 0.75 mm² Mains Power Cable, Black Polyvinyl Chloride PVC Sheath 100m, 6 A 500 V, 3185Y H05VV-F; 492-024
by RS PRO
0₫
Mã kho: 492024
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Cores | 5 |
| Cross Sectional Area | 0.75 mm² |
| Sheath Colour | Black |
| Current Rating | 0.25 |
| Length | 100m |
| Voltage Rating | 500 V |
| Outer Diameter | 8mm |
| Sheath Material | Polyvinyl Chloride PVC |
| Type | 3185Y |
| Minimum Operating Temperature | -15°C |
| Maximum Operating Temperature | +70°C |
| Conductor Strand Type | Stranded |
| Harmonised Code | H05VV-F |
| Standards Met | BS EN 50525 |
| Conductor Material | Copper |
| Size of Strands | 0.2 mm |
| Number of Strands | 24 |
| American Wire Gauge | 18 AWG |
| Conductor Resistance | 26 Ω/km |
| Insulation Material | PVC |
| Core Strands | 24/0.2 mm |
