Panasonic 0.68F Supercapacitor EDLC -30 → +80% Tolerance F Series 5.5V dc Through Hole [EECF5R5H684N]; 869-0705
by Panasonic
0₫
Mã kho: 8690705
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 0.68 F |
Voltage | 5.5 V dc |
Mounting Type | Through Hole |
Minimum Operating Temperature | -40°C |
Maximum Operating Temperature | +85°C |
Diameter | 21.5mm |
Height | 9.5mm |
Dimensions | 21.5 (Dia.) x 9.5mm |
Lead Pitch | 5mm |
Leakage Current | 1 mA |
Lifetime | 1000h |
Series | F |
Tolerance | -30 → +80% |
Product Diameter | 21.5mm |
Dielectric Material Family | Gold |
Tolerance Plus | 0.8 |
Tolerance Minus | -0.3 |
Lead Diameter | 1.2 x 0.5mm |
Capacitor Family | Electric Double Layer |
Terminal Type | Radial |
