Panasonic 0.68F Supercapacitor EDLC -30 → +80% Tolerance F Series 5.5V dc Through Hole [EECF5R5H684N]; 166-6809
by Panasonic
0₫
Mã kho: 1666809
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 0.68 F |
| Voltage | 5.5 V dc |
| Mounting Type | Through Hole |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Diameter | 21.5mm |
| Height | 9.5mm |
| Dimensions | 21.5 (Dia.) x 9.5mm |
| Lead Pitch | 5mm |
| Leakage Current | 1 mA |
| Lifetime | 1000h |
| Series | F |
| Tolerance | -30 → +80% |
| Tolerance Minus | -0.3 |
| Terminal Type | Radial |
| Tolerance Plus | 0.8 |
| Dielectric Material Family | Gold |
| Product Diameter | 21.5mm |
| Capacitor Family | Electric Double Layer |
| Lead Diameter | 1.2 x 0.5mm |
