Supercapacitor 35F 2.7V 20mohm 70uA [SCCU30B356SRB]; 186-2176
by AVX
0₫
Mã kho: 1862176
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 35 F |
| Voltage | 2.3 V dc, 2.7 V dc |
| Mounting Type | Through Hole |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +65 °C, +85 °C |
| Diameter | 16mm |
| Height | 30mm |
| Dimensions | 16 Dia. x 30mm |
| Lead Pitch | 7.5mm |
| Equivalent Series Resistance | 40mΩ |
| Series | SCC |
| Tolerance | -33.3333333333333 |
| Tolerance Minus | -0.1 |
| Capacitor Family | Supercapacitor |
| Tolerance Plus | 0.3 |
| Lead Spacing | 7.5 mm |
| Polarised | Polar |
| Terminal Type | Radial |
| Product Diameter | 16mm |
| Lead Diameter | 0.8mm |
