ROHM BR24L64F-WE2, 64kbit Serial EEPROM Memory, 3500ns 8-Pin SOP Serial-2 Wire [BR24L64F-WE2]; 463-7139
by ROHM
0₫
Mã kho: 4637139
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Memory Size | 64kbit |
| Interface Type | Serial-2 Wire |
| Package Type | SOP |
| Mounting Type | Surface Mount |
| Pin Count | 8 |
| Organisation | 8K x 8 bit |
| Minimum Operating Supply Voltage | 1.8 V |
| Maximum Operating Supply Voltage | 5.5 V |
| Programming Voltage | 1.8 → 5.5V |
| Length | 5mm |
| Width | 4.4mm |
| Height | 1.5mm |
| Dimensions | 5 x 4.4 x 1.5mm |
| Maximum Operating Temperature | +85 °C |
| Minimum Operating Temperature | -40 °C |
| Data Retention | 40yr |
| Maximum Random Access Time | 3500ns |
