Panduit C-Style CU Comp Conn, #6 AWG Sol- #2 AWG Str,1/4” Rod (M); #6 AWG Sol- #2 AWG Str (T) [CTAPR2-2-X]; PAK667

Name: Panduit C-Style CU Comp Conn, #6 AWG Sol- #2 AWG Str,1/4” Rod (M); #6 AWG Sol- #2 AWG Str (T) [CTAPR2-2-X]; PAK667
Brand: Panduit
SKU: PAK667
Price: 220900.0 VND
Availability: InStock

by Panduit

220.900₫

(Giá chưa VAT).

Mã kho: PAK667

Mã nhà sản xuất: CTAPR2-2-X

Đơn vị tính: PC

Quy cách đóng gói: 1

Quantity

Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)

Grounding Bonding / Grounding Compression Connectors Covers / E Style Connectors: Panduit CTAPR2-2-X

MÔ TẢ SẢN PHẨM

The CTAPR2-2-X Compression Connector Tap provides high-strength and premium electrical properties. It is suitable for use with solid and stranded copper Code conductors. Used for tapping conductor to conductor and conductor to ground rod applications. UL listed per UL486 for use suitable for direct

_THÔNG SỐ KỸ THUẬT:

Sub Brand	StructuredGround™
Overall Length (In.)	0.75
Overall Length (mm)	19
Material	High Conductivity Copper
Overall Width (In.)	0.56
Overall Width (mm)	14.2
Overall Height (In.)	1.16
Overall Height (mm)	29.46
Maximum Copper Conductor Size (AWG SOL)	1
Maximum Copper Conductor Size (AWG STR)	2
Minimum Copper Conductor Size (AWG SOL)	6
Minimum Copper Conductor Size (AWG STR)	6
Maximum Ground Rod Size (In.)	1/4
Maximum Ground Rod Size (mm)	6.35
Minimum Ground Rod Size (In.)	1/4
Minimum Ground Rod Size (mm)	6.35
Panduit Die Index Number	Standards Met	cULus Listed for Direct Burial Grounding Applications to UL467 and Power Applications up to 35kV
Application	Utility/Ground Grid
Product Type	Compression Connectors - Taps
