TRACOPOWER, TPC DIN Rail Power Supply, 12V dc Output Voltage, 2.2A Output Current [TPC 030-112]; 808-6645
by TRACOPOWER
0₫
Mã kho: 8086645
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
AC or DC Input Voltage | Ac, Dc |
AC or DC Output Voltage | Dc |
Input Voltage | 85 → 264V ac |
Output Voltage | 12 V dc |
Output Current | 2.2 A |
Power Rating | 26W |
Number of Outputs | 1 |
Electrical Phase | 1 |
Height | 90mm |
Width | 45mm |
Mounting Type | DIN Rail Mount |
Depth | 96.5mm |
Minimum Temperature | -25°C |
Ripple And Noise | 100mV Pk-Pk |
MTBF | 2.2 Millionh |
Load Regulation | 0.005 |
Maximum Temperature | +70°C |
Series | TPC |
