Phoenix Contact, STEP-PS/ 1AC/ 5DC/2 DIN Rail Power Supply, 5V dc Output Voltage, 3.7A Output Current [2320513]; 168-2488
0₫
Mã kho: 1682488
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| AC or DC Input Voltage | Ac, Dc |
| AC or DC Output Voltage | Dc |
| Input Voltage | 85 → 264V ac |
| Output Voltage | 5 V dc |
| Output Current | 3.7 A |
| Power Rating | 12.7W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switched Mode |
| Height | 90mm |
| Width | 18mm |
| Ripple And Noise | 50mV Pk-Pk |
| Minimum Temperature | -25°C |
| Depth | 61mm |
| Mounting Type | DIN Rail Mount |
| Special Features | 000 Hours and U/I Characteristic Curve, Energy Savings Thanks to Maximum Energy Efficiency and Incredibly Low Idling Losses, Flexible Mounting by Simply Snapping onto The Din Rail or Screwing onto A Level Surface, Reliable Power Supply Thanks to High MTBF (mean Time Between Failures) of More Than 500 |
| Series | STEP-PS/ 1AC/ 5DC/2 |
| Standards Met | CE EN61000-6-3, CUL, DIN VDE 0100-410, EMC Directive 2014/30/EU, EN 50121-4, EN 50178, EN 50178/VDE 0160 (PELV), EN 61000-3-2, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-6-2:2005, EN 61558-2-16, IEC 60950-1 (SELV) and EN 60204-1 (PELV), IEC 60950-1/VDE 0805 (SELV), IEC/EN 61000-4-6, NEC Class 2 as per UL 1310, UL/C-UL listed UL 508, UL/C-UL Reconized UL 60950-1 |
| MTBF | 500000h |
| Maximum Temperature | +70°C |
