Mean Well, SDR DIN Rail Power Supply, 12V dc Output Voltage, 6.3A Output Current [SDR-75-12]; 122-2221
by Mean Well
0₫
Mã kho: 1222221
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
AC or DC Input Voltage | Ac |
AC or DC Output Voltage | Dc |
Input Voltage | 88 → 264V ac |
Output Voltage | 12 V dc |
Output Current | 6.3 A |
Power Rating | 75W |
Number of Outputs | 1 |
Electrical Phase | 1 |
Type | Switch Mode |
Height | 125mm |
Width | 102mm |
Special Features | Overvoltage and Short Circuit Protection |
Mounting Type | DIN Rail Mount |
Load Regulation | ±1% |
Ripple And Noise | 100mV Pk-Pk |
Standards Met | RoHS Compliant, TUV EN 60950-1, UL 508 |
Maximum Temperature | +70°C |
Series | SDR |
Depth | 102mm |
Output Voltage Adjustment Range | 12 → 14V |
MTBF | 481.9kh |
Minimum Temperature | -30°C |
