![Mean Well MDR-20-24 428433](http://nguyenxuong.com/cdn/shop/products/R0428433-01_444x362.jpg?v=1593737541)
Mean Well, MDR DIN Rail Panel Mount Power Supply, 24V dc Output Voltage, 1A Output Current [MDR-20-24]; 428-433
by Mean Well
0₫
Mã kho: 428433
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
AC or DC Input Voltage | Ac |
AC or DC Output Voltage | Dc |
Input Voltage | 85 → 264V ac |
Output Voltage | 24 V dc |
Output Current | 0.0416666666666667 |
Power Rating | 20W |
Number of Outputs | 1 |
Electrical Phase | 1 |
Type | Switch Mode |
Height | 100mm |
Width | 22.5mm |
Series | MDR |
Ripple And Noise | 150mV Pk-Pk |
Minimum Temperature | -20°C |
Depth | 90mm |
Mounting Type | DIN Rail Mount |
Standards Met | RoHS Compliant, TUV EN 60950-1, UL 508 |
Special Features | Overvoltage and Short Circuit Protection |
Load Regulation | ±1% |
MTBF | 236900h |
Output Voltage Adjustment Range | 21.6 → 26.4V |
Maximum Temperature | +70°C |
