Mean Well, HDR DIN Rail Power Supply, 15V dc Output Voltage, 6.5A Output Current [HDR-100-15N]; 145-7878
by Mean Well
0₫
Mã kho: 1457878
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
AC or DC Output Voltage | Dc |
Input Voltage | 85 → 264 V ac, 120 → 370 V dc |
Output Voltage | 15 V dc |
Output Current | 6.5 A |
Power Rating | 97.5W |
Number of Outputs | 1 |
Electrical Phase | 1 |
Type | Switch Mode |
Height | 90mm |
Width | 70mm |
Special Features | Small & Compact |
Load Regulation | ±1% |
Output Voltage Adjustment Range | 13.5 → 18V |
MTBF | 856.5kh |
Ripple And Noise | 120mV Pk-Pk |
Minimum Temperature | -30°C |
Depth | 54.5mm |
Mounting Type | DIN Rail |
Series | HDR |
Maximum Temperature | +70°C |
Standards Met | RoHS Compliant, TUV EN 60950-1, UL 508 |
