Mean Well, DDR-60 DIN Rail Panel Mount Power Supply, 15V dc Output Voltage, 4A Output Current [DDR-60L-15]; 175-7790
by Mean Well
0₫
Mã kho: 1757790
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Input Voltage | 18 → 75V dc |
Output Voltage | 15 V dc |
Output Current | 0.166666666666667 |
Power Rating | 60W |
Number of Outputs | 1 |
Height | 90mm |
Width | 52.5mm |
Minimum Temperature | -40°C |
Depth | 54.5mm |
Series | DDR-60 |
Output Voltage Adjustment Range | 13.5 → 16.5V |
Maximum Temperature | +85°C |
MTBF | 611kh |
Load Regulation | ±0.5% |
Mounting Type | DIN Rail Mount |
Ripple And Noise | 75mV Pk-Pk |
