Cosel, KHEA240F DIN Rail Panel Mount Power Supply, 24V dc Output Voltage, 10A Output Current [KHEA240F-24]; 843-1840
by Cosel
0₫
Mã kho: 8431840
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| AC or DC Input Voltage | Ac, Dc |
| AC or DC Output Voltage | Dc |
| Input Voltage | 88 → 264V ac |
| Output Voltage | 24 V dc |
| Output Current | 0.416666666666667 |
| Power Rating | 240W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switch Mode |
| Height | 124mm |
| Width | 50mm |
| Load Regulation | 150mV |
| Output Voltage Adjustment Range | 22.5 to 28.5V |
| Ripple And Noise | 300mV Pk-Pk |
| Efficiency | 92.0 → 94.0% |
| Maximum Temperature | +70°C |
| Series | KHEA240F |
| Minimum Temperature | -25°C |
| Depth | 124mm |
| Mounting Type | DIN Rail Mount |
