RS PRO 32 Way 2.54mm Pitch, Type B Class C1, 1 Row, Straight DIN 41612 Connector, Socket; 508-3038
by RS PRO
0₫
Mã kho: 5083038
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 32 |
| Gender | Female |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Termination Method | Wire Wrap |
| Row Loading | A |
| Type | B |
| Pitch | 2.54mm |
| Contact Plating | Gold over Nickel |
| Class Rating | C1 |
| Current Rating | 2A |
| Contact Material | Brass |
| Maximum Contact Resistance | 20mΩ |
| Maximum Operating Temperature | +125°C |
| Housing Material | PBT |
| Minimum Operating Temperature | -55°C |
| Voltage Rating | 1 kV |
