Cable Accessories, Ties & Tools > Cable Tie Mounts

The cable tie mount in black uses #6 (M3) screws or user supplied adhesive. It measures 1.12" long x 1.12" wide (28.5 x 28.5 mm). It is used with miniature, intermediate, and standard cable ties. It is made of weather-resistant nylon 6.6, which increases

by Panduit
18.600₫
(Giá chưa VAT).
Mã kho: PAJ790

Mã nhà sản xuất: ABM112-S6-D0

Đơn vị tính: PC

Quy cách đóng gói: 500

Liên hệ để có giá tốt (Vietnam: 0898.332.898,  E-mail: SKF@nguyenxuong.com)

Wire Routing Management Protection / Cable Wire Ties Mounts Straps / Cable Tie Mounts: Panduit ABM112-S6-D0

MÔ TẢ SẢN PHẨM

The cable tie mount in black uses #6 (M3) screws or user supplied adhesive. It measures 1.12" long x 1.12" wide (28.5 x 28.5 mm). It is used with miniature, intermediate, and standard cable ties. It is made of weather-resistant nylon 6.6, which increases mechanical strength, heat and wear resistance

_THÔNG SỐ KỸ THUẬT:

Application Used with Miniature, Intermediate, and Standard Cables Ties
Product Type Cable Tie Mount
Color Black
Flammability Rating UL94V-2
Environment Indoor/Outdoor
Material Weather Resistant Nylon 6.6
Maximum Compatible Panel Thickness (In.) 0.04
Maximum Compatible Panel Thickness (mm) 1
Maximum Operating Temperature (°C) 85
Maximum Operating Temperature (°F) 185
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -76
Mount Method Screw
Mounting Hole Thread Size 0.14
Overall Height (In.) 0.2
Overall Height (mm) 5.1
Overall Length (In.) 1.12
Overall Length (mm) 28.4
Overall Width (In.) 1.12
Overall Width (mm) 50.3
Resistance Properties UV Resistant
Standards Met CE Compliant, UL Recognized, RoHS Compliant
Static Load Capacity (kg) 0.3
Sub Brand NA
For Use With Miniature, Intermediate, Standard Cross-Section Ties
