TE Connectivity AMPLIMITE HDP-22 Series Straight Crimp D-sub Connector, Plug, 44 Pin [1658672-1]; 135-4961
0₫
Mã kho: 1354961
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 44 |
| Gender | Male |
| Body Orientation | Straight |
| Mounting Type | Cable Mount |
| Termination Method | Crimp |
| Current Rating | 1.9A |
| Housing Material | Steel |
| Voltage Rating | 250.0 V |
| Length | 53.03mm |
| Width | 12.54mm |
| Depth | 17.32mm |
| Dimensions | 53.03 x 12.54 x 17.32mm |
| Maximum Operating Temperature | +105°C |
| Series | Amplimite HDP-22 |
| Minimum Operating Temperature | -55.0°C |
