TE Connectivity AMPLIMITE 109 Series Series Straight Military Crimp D-Sub Connector, Plug, 50 Pin [1-1757819-0]; 718-3852
0₫
Mã kho: 7183852
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 50 |
| Gender | Male |
| Body Orientation | Straight |
| Mounting Type | Cable Mount |
| Termination Method | Crimp |
| Housing Material | Steel |
| Length | 67.31mm |
| Width | 15.75mm |
| Depth | 16.81mm |
| Dimensions | 67.31 x 15.75 x 16.81mm |
| Contact Plating | Gold over Nickel |
| Minimum Operating Temperature | -55.0°C |
| Contact Material | Copper Alloy |
| Series Number | M24308/4-5Z |
| Maximum Operating Temperature | +125°C |
| Series | Amplimite 109 |
