ERNI TMC Series, 25 Way SMT PCB D-sub Connector Plug, 2.76mm Pitch [164.007]; 170-6860
by Provertha
0₫
Mã kho: 1706860
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 25 |
| Gender | Male |
| Body Orientation | Straight |
| Mounting Type | Surface Mount |
| Pitch | 2.76mm |
| Termination Method | Solder |
| Current Rating | 3.5A |
| Housing Material | Nylon |
| Length | 53.0mm |
| Width | 6.3mm |
| Depth | 13.8mm |
| Dimensions | 53 x 6.3 x 13.8mm |
| Contact Plating | Gold over Palladium Nickel |
| Series | TMC |
| Minimum Operating Temperature | -55.0°C |
| Series Number | 164 |
| Contact Material | Copper Alloy |
| Maximum Operating Temperature | +125°C |
