Glenair MWDM Series, 37 Way Right Angle Through Hole Micro-D PCB Connector Plug, 2.54mm Pitch [MWDM2L-37PCBRP-.110]; 612-6619
by Glenair
0₫
Mã kho: 6126619
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 37 |
| Gender | Male |
| Body Orientation | Right Angle |
| Mounting Type | Through Hole |
| Pitch | 2.54mm |
| Termination Method | Solder |
| Current Rating | 3.0A |
| Housing Material | Aluminium Alloy |
| Length | 37.7mm |
| Width | 7.8mm |
| Depth | 18.1mm |
| Dimensions | 37.7 x 7.8 x 18.1mm |
| Minimum Operating Temperature | -55.0°C |
| Contact Material | Beryllium Copper |
| Contact Plating | Gold over Nickel |
| Maximum Operating Temperature | +150°C |
| Series | MWDM |
