Cinch Connectors D Series Panel Mount, 9 Pin Standard D-Sub D-sub Connector Plug, Shell Size E [DEH-9P-F179]; 885-9046
0₫
Mã kho: 8859046
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 9 |
| Gender | Male |
| Body Orientation | Straight |
| Mounting Type | Panel Mount |
| D Connector Type | Standard D-Sub |
| D-Sub Shell Size | E |
| Termination Method | Solder |
| Current Rating | 5.0A |
| Housing Material | Steel |
| Voltage Rating | 1.25 kV |
| Length | 30.81mm |
| Width | 10.72mm |
| Depth | 12.55mm |
| Dimensions | 30.81 x 10.72 x 12.55mm |
| Series | D |
| Maximum Operating Temperature | +125°C |
| Minimum Operating Temperature | -65.0°C |
| Contact Material | Copper Alloy |
| Contact Plating | Gold Flash over Nickel |
