Binder 910 Series Through Hole, 37 Pin Micro-D Connector D-sub Connector Plug [11-0031-00-37]; 117-5082
by binder
0₫
Mã kho: 1175082
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 37 |
| Gender | Male |
| Body Orientation | Straight |
| Mounting Type | Through Hole |
| Pitch | 1.27mm |
| D Connector Type | Micro-D |
| Termination Method | Solder |
| Current Rating | 3.0A |
| Housing Material | PA |
| Voltage Rating | 250 V dc |
| Contact Material | Copper Alloy |
| Maximum Operating Temperature | +85°C |
| Contact Plating | Gold |
| Series | 910 |
| Minimum Operating Temperature | -40.0°C |
