NDK 16MHz Crystal Unit SMD 2-Pin 5 x 3.2 x 1.3mm [NX5032GA-16.000M-STD-CSU-2]; 184-7960
by NDK
0₫
Mã kho: 1847960
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Standard Frequency | 16MHz |
| Mounting Type | Surface Mount |
| Load Capacitance | 8pF |
| Package Type | SMD |
| Pin Count | 2 |
| Length | 5mm |
| Width | 3.2mm |
| Height | 1.3mm |
| Dimensions | 5 x 3.2 x 1.3mm |
| Frequency Tolerance | ±50ppm |
| Frequency Stability | ±150ppm |
| Series Resistance | 120Ω |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 150°C |
| Automotive Standard | AEC-Q200 |
