NDK 12MHz Crystal ±15ppm SMD 4-Pin 3.2 x 2.5 x 0.55mm [NX3225SA 12MHZ AT-W-STD-CRS-2]; 753-7433
by NDK
0₫
Mã kho: 7537433
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Standard Frequency | 12MHz |
| Mounting Type | Surface Mount |
| Load Capacitance | 8pF |
| Package Type | SMD |
| Pin Count | 4 |
| Length | 3.2mm |
| Width | 2.5mm |
| Height | 0.55mm |
| Dimensions | 3.2 x 2.5 x 0.55mm |
| Frequency Tolerance | ±15ppm |
| Frequency Stability | ±50 x 10^-6 ^-6 |
| Series Resistance | 120Ω |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 125°C |
