NDK 40MHz Crystal Unit SMD 4-Pin 2 x 1.6 x 0.45mm [NX2016SA-40M-STD-CZS-3]; 184-7956
by NDK
0₫
Mã kho: 1847956
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Standard Frequency | 40MHz |
| Mounting Type | Surface Mount |
| Load Capacitance | 8pF |
| Package Type | SMD |
| Pin Count | 4 |
| Length | 2mm |
| Width | 1.6mm |
| Height | 0.45mm |
| Dimensions | 2 x 1.6 x 0.45mm |
| Frequency Tolerance | ±15ppm |
| Frequency Stability | ±50ppm |
| Series Resistance | 50Ω |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 125°C |
| Automotive Standard | AEC-Q200 |
