Hosonic 24.576MHz Crystal ±30ppm SMD 4-Pin 6 x 3.5 x 1mm [E6SB24.5760F20D35]; 675-4772
by Hosonic
0₫
Mã kho: 6754772
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Standard Frequency | 24.576MHz |
| Mounting Type | Surface Mount |
| Load Capacitance | 20pF |
| Package Type | SMD |
| Pin Count | 4 |
| Length | 6mm |
| Width | 3.5mm |
| Height | 1mm |
| Dimensions | 6 x 3.5 x 1mm |
| Frequency Tolerance | ±30ppm |
| Frequency Stability | ±50ppm |
| Series Resistance | 40Ω |
| Minimum Operating Temperature | -10°C |
| Maximum Operating Temperature | 70°C |
