Fox Electronics 22.1184MHz Crystal ±30ppm SMD 2-Pin 11.7 x 5 x 4.5mm [FOXSDLF/221-20]; 173-4332
0₫
Mã kho: 1734332
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Standard Frequency | 22.1184MHz |
Mounting Type | Surface Mount |
Load Capacitance | 20pF |
Package Type | SMD |
Pin Count | 2 |
Length | 11.7mm |
Width | 5mm |
Height | 4.5mm |
Dimensions | 11.7 x 5 x 4.5mm |
Frequency Tolerance | ±30ppm |
Frequency Stability | ±50ppm |
Series Resistance | 30Ω |
Minimum Operating Temperature | -20°C |
Maximum Operating Temperature | 70°C |
