RALTRON 6MHz Crystal ±30ppm HC-49-US SMD 2-Pin [AS-6.000-18-SMD]; 703-7090
by RALTRON
0₫
Mã kho: 7037090
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Standard Frequency | 6MHz |
| Mounting Type | Surface Mount |
| Load Capacitance | 18pF |
| Package Type | HC-49-US SMD |
| Pin Count | 2 |
| Length | 12mm |
| Width | 4.8mm |
| Height | 4.6mm |
| Dimensions | 12 x 4.8 x 4.6mm |
| Frequency Tolerance | ±30ppm |
| Frequency Stability | ±50ppm |
| Series Resistance | 80Ω |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | 70°C |
