TE Connectivity Mini-Universal MATE-N-LOK Series Crimp Terminal, Male, 0.12mm² to 0.35mm², 26AWG to 22AWG [170363-3]; 479-1643
0₫
Mã kho: 4791643
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Gender | Male |
| Series | Mini-Universal MATE-N-LOK |
| Minimum Wire Size mm² | 0.12mm² |
| Termination Method | Crimp |
| Maximum Wire Size mm² | 0.35mm² |
| Minimum Wire Size AWG | 26AWG |
| Contact Plating | Gold over Nickel |
| Maximum Wire Size AWG | 22AWG |
| Contact Material | Brass |
| Maximum Contact Resistance | 10mΩ |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | +105°C |
