LM319MX ON Semiconductor, Dual Comparator, Open Collector O/P, 0.08μs 5 V 14-Pin SOP [LM319MX]; 759-9386
0₫
Mã kho: 7599386
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Comparator Type | High Speed |
Mounting Type | Surface Mount |
Package Type | SOP |
Power Supply Type | Dual, Single |
Output Type | Open Collector |
Number of Channels per Chip | 2 |
Typical Response Time | 0.08µs |
Pin Count | 14 |
Typical Single Supply Voltage | 5 V |
Dimensions | 8.76 x 4.2 x 1.65mm |
Length | 8.76mm |
Width | 4.2mm |
Height | 1.65mm |
Maximum Operating Temperature | +70 °C |
Typical Dual Supply Voltage | ±15V |
Typical Voltage Gain | 40 V/mV |
Minimum Operating Temperature | 0 °C |
