NJU7102AM New Japan Radio, Dual Comparator, Push-Pull O/P, 5 → 9 V 8-Pin DMP [NJU7102AM]; 178-2409
0₫
Mã kho: 1782409
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Comparator Type | Low Power |
| Mounting Type | Surface Mount |
| Package Type | DMP |
| Power Supply Type | Single |
| Output Type | Push-Pull |
| Number of Channels per Chip | 2 |
| Pin Count | 8 |
| Typical Single Supply Voltage | 5 → 9 V |
| Dimensions | 5 x 5 x 1.6mm |
| Length | 5mm |
| Width | 5mm |
| Height | 1.6mm |
| Typical CMRR | 82dB |
| Minimum Operating Temperature | 0 °C |
| Maximum Operating Temperature | +70 °C |
