2 x 12 mH Wurth Elektronik WE-LF Common Mode Choke [7446221012]; 163-7886
0₫
Mã kho: 1637886
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Inductance | 2 x 12 mH |
| Series | WE-LF |
| DC Resistance | 2 x 0.28Ω |
| Maximum Current | 1.2 A |
| Dimensions | 23.5 x 16 x 25.5mm |
| Operating Temperature Range | -40 → +125 °C |
| Mounting Type | Through Hole |
| Minimum Operating Temperature | -40°C |
| Length | 23.5mm |
| Maximum Operating Temperature | +125°C |
| Depth | 16mm |
| Height | 25.5mm |
