Capacitor Disc SLCC 715C 30KVDC 2500PF Y [715C30DKD25]; 197-5984
by Vishay
0₫
Mã kho: 1975984
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2.5 nF |
| Voltage | 10.6 kVrms, 30 kV dc |
| Mounting Type | Screw Mount |
| Series | 715C30DK |
| Tolerance | -19.2 |
| Dielectric | Y5U |
| Diameter | 45.7mm |
| Height | 30mm |
| Dimensions | 45.7 (Dia.) x 30mm |
| Tolerance Minus | -0.2 |
| Terminal Type | Screw |
| Capacitor Family | Single Layer |
| Suppression Class | Class 2 |
| Dissipation Factor | 20 x 10^-3 |
| Dielectric Material Family | Ceramic |
| Tolerance Plus | 0.8 |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -30°C |
