Capacitor Disc SLCC 715C 30KVDC 2500PF Y [715C30DKD25]; 184-9577
by Vishay
0₫
Mã kho: 1849577
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 2.5 nF |
Voltage | 10.6 kVrms, 30 kV dc |
Mounting Type | Screw Mount |
Series | 715C30DK |
Tolerance | -20 → +80% |
Dielectric | Y5U |
Diameter | 45.7mm |
Height | 30mm |
Dimensions | 45.7 Dia. x 30mm |
Dielectric Material Family | Ceramic |
Dissipation Factor | 20 x 10^-3 |
Suppression Class | Class 2 |
Minimum Operating Temperature | -30°C |
Capacitor Family | Single Layer |
Tolerance Minus | -0.2 |
Tolerance Plus | 0.8 |
Terminal Type | Screw |
Maximum Operating Temperature | +85°C |
