Vishay Single Layer Ceramic Capacitor (SLCC) 500pF 20kV dc -20 → +80% Y5U Dielectric 715C Series [715C20DKT50]; 169-3064
by Vishay
0₫
Mã kho: 1693064
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 500 pF |
| Voltage | 20 kV dc |
| Series | 715C |
| Tolerance | -20 → +80% |
| Dielectric | Y5U |
| Package/Case | 814 |
| Diameter | 22.4mm |
| Height | 25.4mm |
| Dimensions | 22.4 (Dia.) x 25.4mm |
| Minimum Operating Temperature | -30°C |
| Dissipation Factor | 20 x 10^-3% |
| Dielectric Material Family | Ceramic |
| Maximum Operating Temperature | +85°C |
| Tolerance Plus | 0.8 |
| Capacitor Family | Single Layer |
| Terminal Type | Screw Terminal |
| Tolerance Minus | -0.2 |
