Capacitor Disc SLCC 715C 10KVDC 20000PF [715C10DKS20]; 184-9574
by Vishay
0₫
Mã kho: 1849574
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 20 nF |
| Voltage | 3.5 kVrms, 10 kV dc |
| Mounting Type | Screw Mount |
| Series | 715C10DK |
| Tolerance | -20 → +80% |
| Dielectric | Y5U |
| Diameter | 54.1mm |
| Height | 19.8mm |
| Dimensions | 54.1 Dia. x 19.8mm |
| Minimum Operating Temperature | -30°C |
| Suppression Class | Class 2 |
| Dissipation Factor | 20 x 10^-3 |
| Dielectric Material Family | Ceramic |
| Tolerance Plus | 0.8 |
| Maximum Operating Temperature | +85°C |
| Capacitor Family | Single Layer |
| Terminal Type | Screw |
| Tolerance Minus | -0.2 |
