Vishay Single Layer Ceramic Capacitor (SLCC) 1nF 15kV dc -20 → +80% Y5U Dielectric 615R Series [615R150GAD10]; 131-1214
by Vishay
0₫
Mã kho: 1311214
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1 nF |
| Voltage | 15 kV dc |
| Series | 615R |
| Tolerance | -20 → +80% |
| Dielectric | Y5U |
| Diameter | 17mm |
| Depth | 10.7mm |
| Dimensions | 17 (Dia.) x 10.7mm |
| Capacitor Family | Single Layer |
| Dissipation Factor | 0.02 |
| Dielectric Material Family | Ceramic |
| Tolerance Plus | 0.8 |
| Maximum Operating Temperature | +105°C |
| Tolerance Minus | -0.2 |
| Terminal Type | Radial |
| Minimum Operating Temperature | -25°C |
