Vishay Single Layer Ceramic Capacitor SLCC 500pF 10kV dc ±20% T3M (N4700) Dielectric 615R Series Through Hole [615R100GATT50]; 831-3317
by Vishay
0₫
Mã kho: 8313317
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 500 pF |
| Voltage | 10 kV dc |
| Mounting Type | Through Hole |
| Series | 615R |
| Tolerance | ±20% |
| Dielectric | T3M (N4700) |
| Diameter | 17.3mm |
| Depth | 8.1mm |
| Dimensions | 17.3 (Dia.) x 8.1 (D)mm |
| Tolerance Plus | 0.2 |
| Tolerance Minus | -0.2 |
| Maximum Operating Temperature | +105°C |
| Minimum Operating Temperature | -25°C |
| Terminal Type | Radial |
