CSTLS8M00G53Z-B0, Ceramic Resonator, 8MHz Shear 15pF, 3-Pin CSTLS, 8 x 3 x 5.5mm [CSTLS8M00G53Z-B0]; 167-4950
by Murata
0₫
Mã kho: 1674950
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resonance Frequency | 8MHz |
| Frequency Tolerance | ±0.5% |
| Mode of Oscillation | Shear |
| Load Capacitance | 15pF |
| Resonance Resistance | 25Ω |
| Mounting Type | Through Hole |
| Package Type | CSTLS |
| Pin Count | 3 |
| Dimensions | 8 x 3 x 5.5mm |
| Height | 5.5mm |
| Length | 8mm |
| Maximum Operating Temperature | 125°C |
| Width | 3mm |
| Minimum Operating Temperature | -40°C |
