Vishay 15F Supercapacitor EDLC -20 → +80% Tolerance 196 HVC Series 4.2V dc Through Hole [MAL219691203E3]; 173-0674
by Vishay
0₫
Mã kho: 1730674
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 15 F |
| Voltage | 4.2 V dc |
| Mounting Type | Through Hole |
| Minimum Operating Temperature | -20°C |
| Maximum Operating Temperature | +85°C |
| Diameter | 12mm |
| Dimensions | 12 (Dia.) x 7.5mm |
| Lead Pitch | 12.5mm |
| Leakage Current | 0.12 mA |
| Equivalent Series Resistance | 1.8 (ac) Ω, 7.5 (dc) Ω |
| Lifetime | 1000h |
| Series | 196 HVC |
| Tolerance | -20 → +80% |
| Lead Diameter | 0.64 mm, 0.8 mm |
| Capacitor Family | Electric Double Layer |
| Tolerance Minus | -0.2 |
| Terminal Type | Radial |
| Tolerance Plus | 0.8 |
| Product Diameter | 12mm |
