SIE Sensorick Capacitive sensor 2 → 25 mm PNP/NPN-NO/NC supply voltage 10 → 30 V dc IP65 [BCS003K]; 377-8504
0₫
Mã kho: 3778504
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Body Style | Barrel |
| Output Type | PNP/NPN-NO/NC |
| Detection Range | 25 mm |
| Supply Voltage | 10 → 30 V dc |
| Terminal Type | Cable |
| IP Rating | IP65 |
| Maximum DC Voltage | 30V |
| Mounting Style | Flush |
| Depth | 10mm |
| Switching Current | 150 mA |
| Dimensions | 50 x 10 mm |
| Maximum Operating Temperature | +60°C |
| Housing Material | POM |
| Minimum Operating Temperature | -30°C |
| Switching Frequency | 50 Hz |
| Short Circuit Overload Protection | Yes |
| Reverse Polarity Protection | Yes |
