| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Thread Size | M18 x 1 |
| Output Type | PNP-NO |
| Detection Range | 20 mm |
| Supply Voltage | 10 → 30 V dc |
| IP Rating | IP68 |
| Maximum DC Voltage | 30V |
| Length | 66mm |
| Width | 18mm |
| Maximum AC Voltage | 250V |
| Switching Current | 200 mA |
| Maximum Operating Temperature | +70°C |
| Switching Frequency | 400 Hz |
| Reverse Polarity Protection | Yes |
| Dimensions | 18 Dia. x 66 mm |
| Housing Material | Brass |
| Short Circuit Overload Protection | Yes |
| Minimum Operating Temperature | -25°C |
